ECO2rack | Transcritical CO2 compressor rack

Rack of compressors subcritical CO2 cycle with double suction in cascade

CO2 air cooled condensation refrigeration plants.

Request technical advice

Description

Transcritical CO2 rack by INTARCON, with single or double suction in a transcritical cycle, offering a total refrigeration capacity from 50 to 300 kW.

  • Transcritical cycle with parallel compression

The transcritical cycle with parallel compression improves energy efficiency at high ambient temperatures.

CONSTRUCTION

  • Construction in a galvanised sheet steel structure with epoxy paint.
  • Instrumentation panel with pressure gauges and charging ports.
  • Sealed electrical panel independent from the refrigeration compartment.
  • Emergency unit for R744 maintenance.

REFRIGERATION CIRCUIT

  • Transcritical R-744 compressor rack and parallel compressor rack. INVERTER drive on one compressor in each rack.
  • Oil separator and oil accumulator with filter and electronic injection per compressor
  • Medium-pressure receiver (PS: 60 bar) with double safety valve piped to the outside.
  • Economizer – liquid subcooler.
  • Double pressure control valve, on receiver and at medium pressure.
  • Double pressure control valve.
  • Receiver pressure regulating valves.
  • Pressure regulating valve with relief to medium pressure.

ELECTRICAL PANEL AND CONTROL

  • Electronic regulation for R-717 transcritical systems, with management of the positive temperature and negative temperature lines in transcritical booster configuration.

CONSTRUCTION

  • Silentblocks for unit installation. (Accessory)

REFRIGERATION CIRCUIT

  • Particle separator and filter.
  • Condensation heat recovery.

ELECTRICAL PANEL AND CONTROL

  • Spare programmed electronic control. (Accessory)
  • Electronic control for heat recovery. (Accessory)

COIL

  • Gas cooler remoto de tubos de cobre y aletas de aluminio en paralelo, PS: 120 bar.
  • EC electronic fans.
  • Polyurethane anti-corrosion coating of the gas cooler.
  • Aqua Aero® anti-corrosion coating of the gas cooler.
